CCD Screen Printer Printing Machine

This is a full servo screen printer with CCD ,servo running working table and safety doors.The CCD platform adopts an XYθ three-axis precision slide platform, to reach the precise position of the printing pattern with high-definition CCD images.The printed pattern is clear and smooth.The whole machine adopts Panasonic control system and touch panel, it is convenient and efficient to operate.Before printing, the CCD automatically adjust the product location,then electrostatic device to remove the static electricity from the product surface.It can print PCB, thin PVC membrane etc.
Availability:
Quantity:
  • OS4V-400

  • OLAT

  • 8443192290

Pad printers and screen printers suitable for printing in plastic rubber, metal glass, ceramic wood products and other materials, widely used in glass cosmetics, stationery office supplies, electronic appliances, process decoration, medicine, ceramics and other fields. Can print exquisite effect on the plane, sphere and surface such as pen ruler, makeup bottle, glass bottle, industrial glove, fishing rod lamp tube long rod, glass touch screen, film circuit, electronic parts, keypad, medical tube, chip, memory card, computer mobile phone furniture tool shell and so on.

CCD Screen Printer Printing Machine
Main performance of CCD screen printing machine :

This is a full servo screen printer with CCD ,servo running working table and safety doors.The CCD platform adopts an XYθ three-axis precision slide platform, to reach the precise position of the printing pattern with high-definition CCD images.The printed pattern is clear and smooth.The whole machine adopts Panasonic control system and touch panel, it is convenient and efficient to operate.Before printing, the CCD automatically adjust the product location,then electrostatic device to remove the static electricity from the product surface.It can print PCB, thin PVC membrane etc.


Product Parameters


Model OS4V-400FV
Printing workpiece shape: Flat
Printing table top size(mm) : 460*600
Maximum frame size(mm):   750*850
Maximum Printing  size(mm): 400*400
Maximum Printing Speed(cycles/hour): 570
Maximum height of  work pieces (mm): 0.05--0.3
Power Requirement : 220V/50HZ/1500W
Pressure requirement(bar): 5-7
Machine Weight(kg): 900
Machine Size(mm): 2000*1380*1900


Company Profile


CCD Screen Printer Printing MachineCCD Screen Printer Printing Machine



CCD Screen Printer Printing Machine

Our Advantages


CCD Screen Printer Printing MachineCCD Screen Printer Printing Machine

Certifications

CCD Screen Printer Printing Machine

After Sales Service and FAQ


CCD Screen Printer Printing Machine
